Tractor Drive Cable Winch Puller For Pulling No Twist Wire Rope

Large Image : Tractor Drive Cable Winch Puller For Pulling No Twist Wire Rope

Product Details:

Place of Origin:	Ningbo,China
Brand Name:	Donghuan
Certification:	ISO
Model Number:	12-A

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Exported Plywood Case
Delivery Time:	3-5 workdays
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 sets per month

Contact Now

Detailed Product Description

Name:	Cable Winch Puller	Type:	Tractor Drive
Ground Clearance(MM):	150	Wheel-base(MM):	1040
Power(HP):	15	Speed(RPM):	2000
High Light:	hand operated wire rope winch , wire take up machine

Tractor Drive Cable Winch Puller For Pulling No Twist Wire Rope

Cable Winch Puller Features

Four gear,forward gear and reverse gear

Double drum,seven groove,protect the wire rope

speedy and convenient

The grinding of walking tractor is reformed from 12 type walking tractor.

Cable Winch Puller Specifications:

Item number	Model	Ground	wheel-base(MM)	Power(HP)	speed(RPM)	Travel speed(KM/H)	Outline	Weight(KG)
Item number	Model	Clearance(MM)	wheel-base(MM)	Power(HP)	speed(RPM)	Travel speed(KM/H)	size(MM)	Weight(KG)
9171	12-A	150	1040	15	2000	3-13	2670x1040x1300	550
9172	12-B	150	1040	15	2000	3-13	2670x1040x1300	600

Gear	Ⅰ	Ⅱ	Ⅲ	IV	reversalⅠ	reversalⅡ
Traction force(T)	60	37	20	12	/	/
Traction speed(M/MN)	11.7	18.9	34.4	55.6	6.2	21.3
